3M CSCAK Abandonment Kits


from only £32.55

3M Cold Shrink Abandonment Kits for LV Power Cables

Cold shrink cable abandonment kits for low voltage (LV) polymeric cables

  • A complete kit to abandon LV cable either temporarily or permanently
  • Environmental sealing and mechanical protection is provided using 3M™ cold shrink technology
  • Designed for single and multi core low voltage power cables up to and including 1.9/3.3kV
  • Cable types include XLPE/PVC insulation, with or without lead sheath and/or armour
  • Improved tough rubber which is suitable for direct burial applications
  • Simple installation no external heat source required
  • Suitable for ship wiring and offshore cables, cables with corrugated aluminium sheath and armoured instrumentation cables up to 5kV

Kit includes:

  • Cold shrink end cap
  • Cold shrink pre-stretched tube
  • Self amalgamating insulation tape
  • Armour/Earth connection components
  • Full installation instructions
Technical Data
  • Tested up to 3.3Kv
Order
Part Number Diameter Range Price Quantity
CSCAK/1 18-12mm £32.55
CSCAK/2 25-18mm £35.91
CSCAK/3 42-25mm £43.16
CSCAK/4 55-42mm £58.75
CSCAK/5 81-56mm £75.08
