House Service Cut Out Fuse Links
from only £3.20 Ex VAT
Lawsons ME & MF type House Service Cut Out Fuse Links (Barrel Shape Fuses)
Designed for use in conventional house service cut-outs, ASTA certified and tested in accordance with BS1361
- MF BS1361 cylindrical house service cut out fuse links
- Ferrule end cap
- Lawson MF & ME series fuses
- 400/415 Volt house service cut-out links to BS1361, IEC60269-3
- Rated voltage : 415V a.c
- Fusing factor: not exceeding 1.5 (class Q1)
- Rated breaking capacity: 33kA at 0.3 p.f (tested at 80kA at 0.15 p.f)
Breaking capacity for these fuse-links is at 33kA at 0.3 p.f however to cater for increasing fault levels all Lawson house service cut -out fuse-links have been ASTA tested to 80kA at 0.15 p.f
These fuse-links comply with the requirements of IEC 60296-3 which forms the basis of the future BS88: Part 3, superseding the current BS 1361
Dimensions of MF Series
A: 57.0mm
B: 30.2mm
C: 16.0mm
Dimensions of ME Series
A: 57.0mm
B: 22.0mm
C: 16.0mm
