Inflatable Duct Seal Bladders


from only £19.43 Ex VAT

Rayflate inflatable duct seal for 32.5 to 180.0mm ducts

  • The Rayflate seal consists of an inflatable bladder with a sealing strip which is fitted around the power cable in a duct and inflated to create a watertight seal
  • Ideal for both new and existing installations
  • Extremely versatile and will adapt to most configurations independent of duct ovality
  • Used in conjunction with an inflation tool and gas cylinder
  • Please contact sales to confirm which products are suitable for empty ducts
Order
Part Number Wolseley Code Alternative Part Number Duct Inside Diameter mm Cable Diameter mm TE Part Number Price Ex VAT Quantity
TDUX-45 RDSS-45 32.5-45.0 0-32.0 £19.43
TDUX-60 JZ2313 RDSS-60 45.0-60.0 0-45.0 £19.95
TDUX-100 CJ1932 RDSS-100 75.0-120.0 0-100.0 £30.70
TDUX-125 CJ4474 RDSS-125 100.0-150.0 0-130.0 £33.39
TDUX-150 CC1467 RDSS-150 125.0-180.0 60-160.0 485455-000 £35.18
